WL-652 - "SOVEREIGN"
MATERIALS GUIDE
SUPPORT
If any issues arise please click here to contact us via email first. We'll walk you through any problems you may be having (with the module).
B.O.M.
for v1.0 boards
MAINBOARD (BOTTOM)
| Part | Value | Qty. | Link | Notes |
|---|---|---|---|---|
| L1 / L2 | 600ohm | 2 | here | |
| C1 / C3 / C5 | 10uF | 3 | here | |
| C9 | 1uF | 1 | here | 1206 SMD, honpolarized |
| C16 | 100nF | 1 | here | 0805 SMD, nonpolarized |
| C13, C14 | 33pF | 4 | here | 0805 SMD, nonpolarized |
| D1, D2 | 1n5817 | 2 | here | |
| R1 / R13 | 1k | 2 | here | all resistors 0805 SMD, 1/8w |
| R8 / R12 | 2.2k | 2 | here | |
| R9 / R10 / R11 | 100k | 3 | here | |
| IC1 | LM567 | 1 | here | via Mouser |
| IC2 | 7809T | 1 | here | |
| IC4 | TL074 | 1 | here | |
| R3 / R11 | 56k | 2 | here | |
| LDR1 | Vactrol | 1 | 5528 LDR / 5mm red LED / 6-7mm Heatshrink | Vactrol guide here |
| Euro Power pins | 2 x 5 | here | 2 rows of 5 | |
| Board Socket | 2 | 4pin and 8pin | one pin of the 8pin socket will have to be bent |
CTL BOARD (TOP)
| Part | Value | Qty. | Link | Notes |
|---|---|---|---|---|
| TUNE / STARVE pots | 1kB | 2 | here | aka "Alpha" - check Thonk.uk if Tayda is out of stock |
| ATTEN | 1kB | 1 | here | 9mm knurled plastic shaft |
| RANGE / MODE switches | 2 | here | SUB MINI on/on switch | |
| All Jacks | 5 | here | aka "Thonkiconn" | |
| Pin Headers | 1x4, 1x7 | here | one row of 4, one row of 7 (cut to size) | |
| R20, R21, R23 | 100k | 3 | here | 0805 SMD, 1/8w |
| R24 | 1k | 1 | here | |
| Nylon Standoffs | 4 | here | ||
| Standoff screws | M3 x 6mm | 8 | here |
BUILD NOTES
-
Nylon screws and standoffs are *REQUIRED*
-
The 7805 should be laid text-side up, flat on the board.
